Wolf01-
Wolf02-

Horsepower:

          145HP
Dimensions:
          20’L x 9’ W x 10' H
Control system:
          Murphy eics

KEY HIGHLIGHTS:

  • High discharge pressure/no need for gas lift valves
  • Single-stage operation leading to increased flow rate at lower pressures
  • World-class component OEMs for reliability and confidence in the field
  • Trailer-mounted version available

Package features:

  • Scrubbers ASME coded with 1/16" corrosion allowance
  • Piping adheres to ASME B31.3
  • API 5th Edition DA2 pulsation and vibration analysis performed for smooth operation
  • Murphy Centurion Panel
  • Rugged four-runner I-beam skid with environmental containment designed to be set on a prepared earth pad
  • Coalescing type fuel gas filter installed for maximum engine protection
  • Inlet spool piece with basket strainer
  • Suction-based speed control
  • Automatic cooler louvers to help maintain proper discharge temperature
  • Scrubber heat tracing virtually eliminates frozen dump valves
  • Insulated scrubbers
  • Shell and tube fuel line heater
  • Oil day tank included for simpler unit mobilization
cta_image

THE WOLF - PERMIAN BASIN CASE STUDY

High-Pressure Gas Lift (HPGL) delivers strong artificial lift performance without the need for well intervention.  But is it really as effective as an ESP?  We partnered with 111-year-old operating company SM Energy to find out.

Email the Case Study

ENGINE: Caterpillar 3306BNA

  • Dependable industry standard G3300 platform backed by Caterpillar's global dealer network
  • Engine Integrated Control System (EICS®)
  • 145 BHP @ 1800 RPM
  • 1.0 NOx, 2.0g CO standard emissions setting
  • Onboard alternator for reliable 24V power
  • Electric starter (24V) for reliable starting independent of gas supply
  • Operator interface included for setup and service without a laptop
  • Pressure-based automatic speed control

Compressor: ariel jgq/2

  • World Standard Compressor backed by Ariel service and support network
  • Available 72-month warranty
Cylinder SIZE PRESSURE
1st Stage Cylinder 2.75” SG-CE 3000 psig
2nd Stage Cylinder 1.625" SG-FS-HE 6100 psig

COOLER: Inducted Draft, Vertical Discharge

  • Right-sized gas cooling sections maintain discharge temperatures, eliminating hydrate formation
  • Final discharge temperature: 250 degrees fahrenheit

  • The Wolf Performance |

  • ENGINE: CATERPILLAR 3306BNA |

  • COMPRESSOR ARIEL JGQ/2 - 2-3/4" X 1-5/8"

hpgl vs esp
Year One cost evaluation

Is HPGL right for your operation? Walk through the Estis HPGL Evaluator, and explore the economic analysis of ESPs and High-Pressure Gas Lift.
